The Blackmagic Design DeckLink Duo 2 is a PCIe capture and playback card built around four independent, offerirectional 3G-SDI connections on a single card, occupying just one PCI Express slot. Each SDI connection can be configured separately as an input or output, allowing simultaneous capture and playback of up to four different SD/HD signals at resolutions up to 1080p60. The card supports 12-bit processing and works with a wide range of codecs, including ProRes, DNxHD/DNxHR, and uncompressed 8-bit and 10-bit 4:2:2 video. It's compatible with Mac, Windows, and Linux, and integrates with major NLE, switching, and streaming software such as DaVinci Resolve, Premiere Pro, Final Cut Pro X, Avid Media Composer, Wirecast, and vMix. Typical applications include multi-channel live capture, media playout servers, multi-screen digital signage, and custom broadcast or OEM systems.
Features
- 4x independent 3G-SDI I/O, each configurable as input or output
- Simultaneous capture and playback across channels
- 12-bit SD/HD processing up to 1080p60
- 16-channel embedded SDI audio, in and out
- Reference input for black burst/tri-sync genlock
What's Included
- (1x) Blackmagic Design DeckLink Duo 2
