Hardware SummaryGeneral

• Physical Connectivity:
  • 1000BASE-T Access Ports (supporting both Half- and Full-Duplex)
  • 1000BASE-SFP Combo Network Uplink Ports
  • 10GBASE-SFP+ Network Uplink Ports
• Switching Fabric:
  • 188Gbps (Full-Duplex) for 50-port models
• Frame Forwarding:
  • 130Mpps for 50-port models
• Nominal Latency: 3.5 microseconds for 64 Byte packets
• Nominal Jitter: 0.84 microseconds for 64 Byte packets
• Frame Length: 64 to 1518 Bytes (Untagged), 64 to 1522 Bytes (Tagged)
• Jumbo Frame: up to 9,216 Bytes (802.1Q Tagged)
• Stackable Chassis Throughput: 24Gbps (Full-Duplex) per Switch, up to 192Gbps

Layer 2

• MAC Address: up to 16,384
• Port-based VLANs: 256
• MSTP Instances: 8
• MLT/LACP Groups: 6
• Links per MLT/LACP Group: 4
• DHCP Snooping Entries: up to 512
• 802.1X Clients: 32 per Port
• LLDP Neighbors: up to 816

Layer 3 IPv4 Routing Services

• ARP Entries: up to 512
• Static ARP Entries: up to 256
• IP Interfaces: up to 64
• IP Routes: up to 256
• IP Static Routes: up to 32
• IP Route Policies: up to 64
• RIP Interfaces: up to 16
• RIP Routes: up to 256

Layer 3 IPv6 Routing Services

• IPv6 Interfaces: 256
• IP Routes: up to 2,048
• IPv6 Static Neighbors: 256
• CLIP Interfaces: 16
• IPv6 Management Tunnels: 4
• IPv6 Data Tunnels: 8
• IPv4/IPv6 Dual Stack
• Router Advertisement Guard
• DHCPv6 Guard
• MLDv1/v2 Snooping
• Duplicate Address Detection and Snooping
• Neighbor Unreachability Detection and Filtering

Multicast

• IGMP Enabled VLANs: 256
• IP Multicast Groups: up to 248

QoS and Filtering

• QoS Precedences: 8
• QoS Filters per Switch: 256 per Precedence
