Mini PCIE to SATA adapter card Mini PCIE hard disk expansion card 2 ports 4 ports sata3.0 Flying Niu QunhuiAttention!!!
This product is only suitable for standard mini pci-e slots, not msata or wireless network interface card slots nor pci-e slots and pci slots!!!
MiniPCL-Express SATA expansion card can be extended to 2 or 4 SATA 3.0 interfaces, using the native PCI Express 2.0 bus. This card supports SATA 6Gbps devices that comply with the SATA 3.0 specification, and is also backward compatible with SATA 15Gbps and 3.0Gbps device functional characteristics
2-Channel M.2 PCl-Express 2.0 interface B + M Key).
Support PCL-Express data transfer rate up to 5.0/2 Gbps.
Support for IDE programming interface registers for SATA controllers.
Support for providing AHCI programming interface registers for SATA controllers.
Support for Message Signaled Interrupts (MSI)
Compliant with Serial ATA specification 3.0.
Support communication speed 6.0Gbps, 3.0Gbps, 1.5Gbps.
Supports programmable transmitter signal levels.
Support Gen 1i, Gen 1x, Gen 2i, Gen 2m, Gen 2x and Gen 3i.
Supports 2/4 SATA ports.
Support for Native Command Queue (NCQ)
Port increase based on FIS
Attention: RAID to PM is not supported
SATA controller
Compliant with Serial ATA specification 3.1 supports 6 GbPS, 3 Gbps and 1.5 Gbps communication speeds support programmable transmitter signal levels
Supports Gen 1i, Gen 1x, Gen 2i, Gen 2m, Gen 2x and Gen 3i Supports four SATA ports Supports AHCI 1.0 and IDE programming interface Supports native command queue (NCO) Supports port-based FIS or command-based switching Supports partial and sleep power management status Supports interleaved rotation Supports AES-256

Name:
Mini PCle to four-port SATA3.0 adapter card
number of interfaces
4 SATA 3.0 interfaces
Applicable slot
Mini PCle
bus bandwidth
About 6Gb/s
Adopt chip
Marvell88SE9215
driver support
No driver required, plug and play
support system
Windows7/8/10/11/Linux/Flying Bull/Qunhui
Product size
50*30mm
