Connector(s)

Connector Type(s)

1 - PCI Express x4

Internal Ports

2 - M.2 (SATA, B-Key, NGFF)

1 - M.2 (PCIe, M-Key, AHCI/NVMe, NGFF)

2 - SATA (7 pin, Data)

Environmental

Operating Temperature

5°C to 50°C (41°F to 122°F)

Storage Temperature

-25°C to 70°C (-13°F to 158°F)

Humidity

20%~80% RH (Non-condensing)

Hardware

Ports

3

Interface

M.2 SATA

SATA

M.2 PCIe

Bus Type

PCI Express

Card Type

Standard Profile (LP bracket incl.)

Port Style

Integrated on Card

Industry Standards

Serial ATA 3.0 specification - SATA I/II/III (1.5/3/6Gbps)

PCI Express 3.0

Indicators

LED Indicators

3 - M.2 drive status/activity

1 - Power

Performance

Type and Rate

SATA III (6 Gbps)

Port Multiplier

No

Bootable

Yes

Hardware Raid Supported

No

ATAPI Support

Yes

MTBF

50,000 Hours
