WAVLINK AC1200 Outdoor Mesh Extender/Router, Long Range IP65 Waterproof WiFi Repeater with Passive/Active POE, Supports Fat/Fit AP, Dual Band 5G+2.4G, 4x7dBi Omni Antennas, Enterprise-grade Encryption

1200Mbps Dual-Band Speed: Use the WAVLINK WING 12HP to dominate bandwidth-heavy environments with split-scenario optimization. The 5GHz Band 867Mbps is dedicated to 4K video surveillance feeds, while the 2.4GHz Band 300Mbps handles 64-96 low-bandwidth IoT devices smart irrigation sensors, RFID tags, POS systems without congestion.

Blanket Every Acre with Mesh Network: Build a bulletproof WiFi blanket across vast homesteads with WAVLINK's Everything Mesh Technology. Seamlessly connect your farmhouse, barns, poultry coops, and distant irrigation hubs into one network. As you move from the kitchen to the yard, from the stable to the farm, enjoy uninterrupted connectivity without drops or lags. Note: It only meshes with WAVLINK devices which support everything mesh technology.

Industrial-Grade Signal Dominance: Powered by a high-power chip and 4x 7dBi antennas 2x 2.4GHz + 2x 5GHz, this outdoor WiFi booster expands signal to 300m away per unit Change with the actual environment, effortlessly linking barns, pastures, and farmhouse basements. Engineered for outdoor scenarios, it juggles 64-96 devices simultaneously—from GPS cattle collars and smart milking systems to 4K yard cams—without throttling.

Dual Gigabit Ports & PoE Freedom: Equipped with dual 10/100/1000Mbps Ethernet ports, the outdoor AP enables lightning-fast data transfer rates and provides an extra wired connection possibility for flexible use. 54V Active/Passive PoE allows you to power the device via Ethernet from 100m away, getting rid of risky outdoor wiring needed. Note: The PoE converter is not waterproof, please install it indoors.

Weatherproof Enclosure & Enterprise-grade Security: IP65 waterproof & heat-resistant case ensures continued operation on harsh outdoor environments, withstanding broad ranges of temperature -20°C~50°C, while 15KV ESD/4KV lightning protection prevents damage in electrical surges. Supporting WPA2/WPA3-MIX and WPA/WPA2-Enterprise, this outdoor router is perfect for businesses, organizations, and individuals requiring high-level security.

Fat/Fit AP Mode Flexibility: Under Fat AP Mode, the repeater works as a regular wireless AP, ideal for quick deployments without complex configurations. Fit AP Mode unlocks centralized control via a WAVLINK AC Controller sold separately, allowing large-scale management — imagine updating firmware on multiple routers spanning 5,000-acre cattle ranches or balancing bandwidth for 10-villa eco-resorts from one dashboard.

Specifications:
- Model: WL-WN572HP3-B/WING 12HP
- Frequency: 2.4GHz & 5GHz, speed up to 1,200Mbps
- Interfaces: 1x 10/100/1,000Mbps WAN, 1 x 10/100/1,000Mbps LAN
- Antennas: 4 x 7dBi omni antennas
- Operation modes: Repeater, AP FAT/FIT, Mesh Router, Mesh Extender
- IP65 Waterproof: 15KV ESD and 4KV lightning protection
- Security: WPA2-PSK, WPA1-PSK/WPA2-MIX, WPA3-SAE/WPA2-PSK, WPA/WPA2-Enterprise, Open.
- LEDs: 7 x status LED indicators
- Power adapter: 100-240V/50-60HZ; DC 54V Active PoE and Passive POE
- Support 802.3 AT/AF Active PoE and Passive PoE to supply power.
- Support Fat AP Mode.
- Support Fit AP Mode with WAVLINK AC controller.
- Distance: Outdoor 200m Change with the actual environment
- Unit Size without antennas: 21.5cm x 6.2cm x 6.2cm / 8.5x 2.4x 2.4in
- Antenna Length: 25cm / 9.8in

Warm Tips
1. The PoE converter is not waterproof, please install it indoors.
2. Please make sure your Ethernet cable to the outdoor router is CAT5E or above certified and shorter than 100m/328ft.
3. Please install the product 2-3 meters above the ground for better performance.
4. Select the wireless network with a signal strength greater than 70% to get the most reliable connection.
5. Under Mesh Mode, it only meshes with WAVLINK devices which support everything mesh technology.

In the Box
- 1 x AC1200 Wireless Outdoor Access Point
- 4 x Omni Antennas
- 1 x RJ-45 Networking Cable
- 1 x Power Adapter
- 1 x PoE Converter
- 1 x Main Body Holder
- 2 x Cable Ties
- 1 x Screw Fittings
- 1 x Quick Start Guide

Designed for Harsh Outdoor Conditions- Equipped with IP67 waterproof enclosure, 15kV ESD protection and 6kV lightning protection, it can work normally in rain/snow/wind/thunder and other bad weather. The fiberglass tube high-gain antennas can not only withstand strong wind and corrosion, but also boost the WiFi coverage, making it more suitable for outdoor use.

Enjoy True WiFi 6 Speed- The next generation of WiFi, complies with IEEE 802.11 ac/a/b/g/n standards. Supports dual-band maximum speed up to 5GHz 1201Mbps and 2.4GHz 574Mbps, avoiding wireless interference & congestion and offering lightning-fast Internet speed. With WAVLINK WN573HX1, you can enjoy HD videos, smooth gaming, etc. even outdoors.

Optional PoE Power Supply- Supports 802.3AF/AT active PoE and passive PoE, transferring data and charging the product with a single Ethernet cable, so you can install the product outdoors where power outlet is not available. Note: The PoE converter is not waterproof. Please use CAT5E or above cable and the length should not exceed 100m/328ft.

Seamless WiFi Roaming- The 4x8dBi omnidirectional antennas and two built-in high-power amplifiers provide extreme WiFi coverage and penetration. Also supports Mesh technology, one-click brings more device connections, greatly expanding the WiFi coverage, and eliminating every network dead zone.

Multiple Modes, Flexible Use- Supports Mesh, AP, Router, Repeater, AP+Repeater and other modes to meet your different needs and apply to more outdoor connection scenarios. Router/AP Mode is ideal for converting wired connections into wireless networks, while under Mesh Mode you can enjoy seamless WiFi with a single network name and password.

Specification
- Model: WL-WN573HX1
- Product Size without antennas: 24x24x7cm / 9.4x9.4x2.8in
- PoE Converter Size: 4.4x3.7x2.2cm / 1.7x1.5x0.9in
- Length: Antennas - 40cm/15.7in; Ethernet Cable - 100cm/39.4in; Power Adapter Cable - 130cm/51.2in
- Product Weight without antennas: 1109g / 39.1oz
- Standard: IEEE 802.11 ax/ac/a/n/g/b
- Frequency Band/Speed: 2.4GHz 574Mbps + 5GHz 1201Mbps
- Wireless Security: WPA2-PSK, WPA2/WPA3-MIX
- Antennas: 4 x 8dBi Omnidirectional Antennas
- PAIR/RESET LED: Blue
- PoE Converter Status LED: Green

Features
- Robust weatherproof case, IP67 waterproof rating and built-in lightning arrester 15kV ESD withstands harsh outdoor conditions.
- Supports 802.3 AT/AF active PoE and passive PoE to supply power.
- Fiberlass tube antennas for high precision, corrosion resistance, long life, strong wind resistance.
- 4x8dBi detachable omnidirectional external antennas provide excellent wireless performance.
- Supports dual band 2.4G 573Mbps + 5G 1201Mbps with combined speeds of up to 1800Mbps.
- Mesh technology makes you enjoy seamless roaming throughout the house with a single network name and password.
- Complies with IEEE 802.11 ax/ac/a/n/g/b standards.
- Supports Mesh/AP/Router/Repeater/AP+Repeater modes.
- Encryption type: WPA2-PSK, WPA3/WPA2-MIX.

Warm Tips
① The PoE converter is not waterproof, please install it indoors.
② Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100m/328ft.
③ Please install the product 2-3 meters above the ground for better performance.
④ Under the mesh mode, WN573HX1 ONLY supports interconnection with WN531AX2, WN583AX1 and WN573HX1.

In the Box
1 x Wi-Fi6 Outdoor Mesh Router/AP/Repeater
4 x Omni Antennas
4 x Cable Ties
1 x Ethernet Cable Connectors
1 x Quick Installation
1 x Wrench
2 x Silicone Pads
Several Screws
Passive PoE Optional:
1 x 54V Power Adapter
1 x PoE Converter
1 x Ethernet Cable

Designed for Harsh Outdoor Conditions- Equipped with IP67 waterproof enclosure, 15kV ESD protection and 6kV lightning protection, it can work normally in rain/snow/wind/thunder and other bad weather. The fiberglass tube high-gain antennas can not only withstand strong wind and corrosion, but also boost the WiFi coverage, making it more suitable for outdoor use.

Enjoy True WiFi 6 Speed- The next generation of WiFi, complies with IEEE 802.11 ac/a/b/g/n standards. Supports dual-band maximum speed up to 5GHz 2402Mbps and 2.4GHz 573Mbps, avoiding wireless interference & congestion and offering lightning-fast Internet speed. With WAVLINK WN573HX3, you can enjoy HD videos, smooth gaming, etc. even outdoors.

Optional PoE Power Supply- Supports 802.3AF/AT active PoE and passive PoE, transferring data and charging the product with a single Ethernet cable, so you can install the product outdoors where power outlet is not available. Note: The PoE converter is not waterproof. Please use CAT5E or above cable and the length should not exceed 100m/328ft.

Seamless WiFi Roaming- The 4x8dBi omnidirectional antennas and two built-in high-power amplifiers provide extreme WiFi coverage and penetration. Also supports Mesh technology, one-click brings more device connections, greatly expanding the WiFi coverage, and eliminating every network dead zone.

Multiple Modes, Flexible Use- Supports Mesh, AP, Router, Repeater, AP+Repeater and other modes to meet your different needs and apply to more outdoor connection scenarios. Router/AP Mode is ideal for converting wired connections into wireless networks, while under Mesh mode you can enjoy seamless WiFi with a single network name and password.

Specification
- Model: WL-WN573HX3
- Product Size without antennas: 24x24x7cm / 9.4x9.4x2.8in
- PoE Converter Size: 4.4x3.7x2.2cm / 1.7x1.5x0.9in
- Length: Antennas - 40cm/15.7in; Ethernet Cable - 100cm/39.4in; Power Adapter Cable - 130cm/51.2in
- Product Weight without antennas: 1109g / 39.1oz
- Standard: IEEE 802.11 ax/ac/a/n/g/b
- Frequency Band/Speed: 2.4GHz 573Mbps + 5GHz 2402Mbps
- Wireless Security: WPA2-PSK, WPA2/WPA3-MIX
- Antennas: 4 x 8dBi Omnidirectional Antennas
- PAIR/RESET LED: Blue
- PoE Converter Status LED: Green

Warm Tips
① The PoE converter is not waterproof, please install it indoors.
② Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100m/328ft.
③ Please install the product 2-3 meters above the ground for better performance.
④ Under the mesh mode, WN573HX3 supports interconnection with WN586X3, WN572HP3 with latest firmware required and WN573HX3.

In the Box
1 x AX3000WiFi 6 Outdoor Access Point
4 x Omni Antennas
4 x Cable Ties
1 x Ethernet Cable Connectors
1 x Quick Installation
1 x Wrench
2 x Silicone Pads
Several Screws
Passive PoE Optional:
1 x 54V Power Adapter
1 x PoE Converter
1 x Ethernet Cable

Designed for Harsh Outdoor Conditions- IP67-rated waterproof housing that ensures continued operation on harsh outdoor environments or in climates of extreme cold, heat or continuous moisture. Lightning protection and weatheproof design ensure stable connection in harsh outdoor conditions. Note: The PoE part of the router is not waterproof.

Enjoy True WiFi 6 Speed- The next generation of WiFi, complies with IEEE 802.11 ac/a/b/g/n standards. Supports dual-band maximum speed up to 5GHz 2402Mbps and 2.4GHz 573Mbps, avoiding wireless interference & congestion and offering lightning-fast Internet speed. With WAVLINK WN573HP3, you can enjoy HD videos, smooth gaming, etc. even outdoors.

Optional PoE Power Supply- Supports 802.3AF/AT active PoE and passive PoE, transferring data and charging the product with a single Ethernet cable, so you can install the product outdoors where power outlet is not available. Note: The PoE converter is not waterproof. Please use CAT5E or above cable and the length should not exceed 100m/328ft.

Seamless WiFi Roaming- The built-in 4x12dBi directional antennas and high-power amplifiers provide extreme WiFi coverage and penetration. Also supports Everything Mesh technology, one-click brings more device connections, greatly expanding the WiFi coverage, and eliminating every network dead zone.

Multiple Modes, Flexible Use- Supports Mesh, AP, Router, Repeater, AP+Repeater and other modes to meet your different needs and apply to more outdoor connection scenarios. Router/AP mode is ideal for converting wired connections into wireless networks, while under Mesh mode you can enjoy seamless WiFi with a single network name and password.

3Km Wireless Data Transmission- Specially designed for outdoor uses, ideal for long distance wireless data transmission over 3km/1.9 miles only for paired PtP or PtMP transmission, tested in the barrier-free field. Built-in 12dBi directional antennas can significantly improve the transmission and reception performance of wireless signal.

Specification
- Model: WL-WN573HP3
- Product Size: 24x24x7cm / 9.4x9.4x2.8in
- PoE Converter Size: 4.4x3.7x2.2cm / 1.7x1.5x0.9in
- Length: Ethernet Cable - 100cm/39.4in; Power Adapter Cable - 130cm/51.2in
- Product Weight: 1050g / 37oz
- Standard: IEEE 802.11 ax/ac/a/n/g/b
- Frequency Band/Speed: 2.4GHz 573Mbps + 5GHz 2402Mbps
- Wireless Security: WPA2-PSK, WPA2/WPA3-MIX
- Antennas: 4 x 12dBi Directional Antennas
- PAIR/RESET LED: Blue
- PoE Converter Status LED: Green

Warm Tips
① The PoE converter is not waterproof, please install it indoors.
② Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100m/328ft.
③ Please install the product 2-3 meters above the ground for better performance.
④ Under the mesh mode, WN573HP3 supports interconnection with WN586X3, WN583AX3 and WN573HX3.
⑤ The real performance of the product may vary in accordance with different environmental conditions.

In the Box
- 1 × AX3000 WiFi 6 Outdoor Access Point
- 1 × 54V Power Adapter
- 4 × Cable Ties
- 1 × PoE Converter
- 2 × Silicone Pads
- 1 × Ethernet Cable
- 1 × Main Body Holder
- 1 × PWM M4×8×8MM Screw
- 1 × Wrench
- 6 × KA M4×25×6MM Screws
- 1 × Quick Start Guide
- 6 × Φ8x25MM Screw Plugs

Designed for Harsh Outdoor Conditions- IP67-rated waterproof housing that ensures continued operation on harsh outdoor environments or in climates of extreme cold, heat or continuous moisture. Lightning protection and weatheproof design ensure stable connection in harsh outdoor conditions. Note: The PoE part of the router is not waterproof.

Enjoy True WiFi 6 Speed- The next generation of WiFi, complies with IEEE 802.11 ac/a/b/g/n standards. Supports dual-band maximum speed up to 5GHz 2402Mbps and 2.4GHz 573Mbps, avoiding wireless interference & congestion and offering lightning-fast Internet speed. With WAVLINK WN588HX3, you can enjoy HD videos, smooth gaming, etc. even outdoors.

Seamless WiFi Roaming- The 6x7dBi omni-directional antennas and high-power amplifiers provide extreme WiFi coverage and penetration. Also supports Everything Mesh technology, one-click brings more device connections, greatly expanding the WiFi coverage, and eliminating every network dead zone.

Multiple Modes, Flexible Use- Supports Mesh, AP, Router, Repeater, AP+Repeater and other modes to meet your different needs and apply to more outdoor connection scenarios. Router/AP mode is ideal for converting wired connections into wireless networks, while under Mesh mode you can enjoy seamless WiFi with a single network name and password.

Powered by PoE and Flexible Installation- Supporting 802.3af/802.3at/48V PoE Power over Ethernet with the included PoE adapter, this device offers flexible deployment and convenient installation with its mounting bracket design. It can be easily mounted on poles or walls.

Specification
- Model: WL-WN588HX3
- Product Size: 17x17.3x5.1cm / 6.7x6.8x2in
- PoE Converter Size: 4.4x3.7x2.2cm / 1.7x1.5x0.9in
- Length: Ethernet Cable - 100cm/39.4in; Power Adapter Cable - 130cm/51.2in
- Product Weight: 552g / 19.5oz
- Standard: IEEE 802.11 ax/ac/a/n/g/b
- Frequency Band/Speed: 2.4GHz 573Mbps + 5GHz 2402Mbps
- Wireless Security: WPA2-PSK, WPA2/WPA3-MIX
- Antennas: 6 x 7dBi Directional Antennas
- PAIR/RESET LED: Blue
- PoE Converter Status LED: Green

Features
- Supports for dual band 2.4G 573Mbps + 5G 2402Mbps with the aggregated speeds up to 3000Mbps.
- Supports one WAN/LAN Ethernet Gigabit port.
- Complies with IEEE 802.1 ax/ac/n/g/a/b standards.
- 3x7dBi 5GHz, 3x7dBi 2.4GHz detachable omni-directional external antennas provide excellent wireless performance.
- Supports Router/AP/Range Extender/Mesh Router/Mesh Extender mode.
- Encryption type: OPEN, WPA2-PSK, WPA3/WPA2 MIX.
- Seamless and stable WiFi Mesh makes you enjoy seamless roaming throughout the house with a single network name and password.
- Robust weatherproof case and IP67 waterproof grade withstand harsh outdoor conditions.
- Supports 802.3 AT/AF Active PoE and Passive PoE to supply power.
- Supports Fat AP Mode.
- Supports Fit AP Mode with WAVLINK AC controller.

Warm Tips
① The PoE converter is not waterproof, please install it indoors.
② Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100m/328ft.
③ Under the mesh mode, WN588HX3 supports interconnection with WN586X3, WN583AX3 and WN573HX3.
④ The real performance of the product may vary in accordance with different environmental conditions.

In the Box
- 1 × AX3000 WiFi 6 Outdoor Access Point
- 4 × Plastic Cable Ties
- 1 × Main Body Holder
- 6 x 7dBi Antennas
- 1 × Wrench
- 1 × 54V Power Adapter
- 1 × PoE Converter
- 1 × Ethernet Cable
- 1 × PWM M3×5×6MM Screw
- 6 × KA M3×20×5.2MM Screws
- 6 × Φ6.5x25MM Screw Plugs
- 1 × Quick Start Guide

Next-Gen Wi-Fi 7 Performance- Experience the future of wireless connectivity with Wi-Fi 7 dual-band technology, delivering blazing speeds of 688Mbps on 2.4GHz and 4323Mbps on 5GHz for a combined throughput up to 5100Mbps. Stream 4K videos without buffering, dominate competitive gaming with near-zero latency, and browse complex websites instantly.

Strong Environmental Resilience- Engineered for extreme conditions, our IP67-rated waterproof and dustproof enclosure shrugs off torrential rains, dust storms, and debris. Built-in 15KV ESD protection and 4KV lightning surge defense safeguard critical components during electrical storms, ensuring rock-solid stability in coastal areas, industrial sites, or mountainous terrain.

Flexible Enterprise & Rural Power Options- Deploy anywhere with dual PoE support: Active PoE 802.3at/af enables plug-and-play installation in high-density environments like hospitals and campuses, while Passive PoE delivers cost-effective, long-range power for rural farms, orchards, and music festivals.

Expansive Coverage with Intelligent Roaming- Four 8dBi high-gain fiberglass antennas create 360° signal coverage for outdoor areas, while the dedicated 5dBi antenna fills near-ground blind zones. Combined with WAVLINK Everything Mesh, one-click connection creates a unified mesh network.

Five Adaptive Operation Modes- Transform this router to fit any scenario: router/AP mode converts wired networks to Wi-Fi hotspots; repeater extends weak signals; mesh router/extender creates seamless multi-node systems; and mesh AP integrates with existing infrastructure. Maintain a single network name SSID across all modes for effortless scaling.

Feature
Frequency: dual-band 2.4GHz at 688Mbps + 5GHz at 4323Mbps, speed up to 5100Mbps.
Ethernet port: 1x2.5G WAN/LAN.
Antennas: 4x8dBi + 1x5dBi high-gain antennas.
Operation modes: mesh AP, AP, repeater, mesh router, and mesh extender.
Security: WPA3-SAE/WPA2-PSK, WPA2-PSK, WPA PSK/WPA2PSK-MIX.
Power adapter: 100-240V/50-60Hz; DC 54V Passive PoE; DC 48V Active PoE.
IP 67 waterproof, 15KV ESD, and 4KV lightning protection.
Complies with IEEE 802.11 be/ax/ac/a/n/g/b standards.
Supports 802.3 AT/AF PoE and Passive PoE to supply power.

Warm Tips
① The PoE converter is not waterproof; please install it indoors.
② Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100 m/328 ft.
③ Please install the product 2–3 meters above the ground for better performance.
④ Under the mesh mode, WN573HBE2 supports interconnection with WN586X3, WN572HP3 with latest firmware required, and WN573HBE2.

Packing List
-1 x BE5100 WiFi7 Outdoor AP
-1 x 54V Power Adapter
-1 x PoE Converter
-1 x Ethernet Cable
-1 x Main Body Holder
-4 x Omni Antennas
-2 x Stainless Steel Hose Clamps
-2 x Silicone Pads
-1 x Slotted Screwdriver
-1 x Wrench
-1 x Quick Start Guide
-Several Screws
