1x 10/100/1000Base-T RJ45 to 1x 1000Base-X SFP Slot Mini Gigabit Ethernet Media Converter, AC 100V~240V

The UMC-GA1F1T Mini Gigabit Ethernet Media Converter bridges 1000Base-X fiber to 10/100/1000Base-T copper networks, enabling fiber extensions up to 2KM (Multimode) or 160KM (Single Mode/WDM) via SFP modules. It features integrated LED indicators (Power, Link, Activity, Speed) for easy status monitoring and maintenance, helping reduce network downtime. With built-in Link Fault Pass-through (LFP) technology, the UMC-GA1F1T enhances troubleshooting efficiency and network reliability. Supportingchassisinstallation, it is a flexible solution for ISP infrastructures and small office deployments. It is also compatible with various transceivers, including 1000Base SFP, offerI, and CWDM modules. Be sure that the wavelength, speed rate, and the distance of the transceiver modules used at both ends of the media converter are consistent.

SpecificationsPorts1 x Gigabit SFP Port
1 x 10/100/1000M RJ45 Port (Auto MDI/MDIX)Standards and ProtocolsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3xCable Type (Fiber)Multimode 50/125µm, 62.5/125µm
Single-mode 9/125µmCable Type (Copper)UTP Cat 5, 5e, 6 Cable (Maxium 100m)
EIA/TIA-568 100Ω STP (Maximum 100m)LED IndicatorsTP/LNK,1000M, FX/LNK, PWRDIP SwitchLFP/ ALS/ FX Speed/FX ResetPower ConsumptionFull-load<3WJumbo Frame12KOperation Mode10/100Mbps for Half/Full Duplex
1000Mbps for Full DuplexDimensions (HxWxD)0.79''x2.36''x3.54'' (20x60x90mm)MTBF (hrs)>50,000HrsLatency1usExternal PowerAC 100V~240VInput PowerDC 5-12VOperating Temperature0°C to 40°CStorage Temperature-20°C to 85°CMatching ProductsMFMC-12DP
