central processing unitSupports CPUs up to 16 coresAMD SocketTR4 supports AMD Ryzen™ Threadripper™ processorsChipsetAMD X399memory8 x DIMMs, capacities up to 128GB, DDR4 3600 (overclocked)/3200 (overclocked)/2800 (overclocked)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered memory *AMD Ryzen™ Threadripper™ processorQuad channel memory architecture*Hyper DIMM support is based on the physical characteristics of the CPU.Multiple graphics display technologySupports AMD 4-way CrossFireX technologySupports NVIDIA 4-way SLI™ technology®Expansion slots4 x PCIe 3.0 x16 (x16, x16/x16, x16/x8/x16, x16/x8/x16/x8) *11 x PCIe 2.0 x4 expansion card slotAMD X399 chip1 x PCIe 2.0 x1 expansion card slotStorage capabilities (depending on shipment)2 x M.2 Socket 3 slots supporting M key, 2242/2260/2280/22110 type storage devices (PCIE 3.0 x 4 mode)*21 x U.2 connector*3AMD Ryzen™ Threadripper™ processor: 1 x M.2 Socket 3 slot with M key, 2242/2260/2280 type storage devices (SATA & PCIE mode)AMD X399 chip : 6 x SATA 6Gb/s interface,Supports RAID 0, 1, 10Network capabilitiesROG GameFirst IV Gaming Low Latency Technology*LANGuard network security protection against power surgeIntel I211-AT, 1 x Gigabit network card®Wireless connectionWi-Fi 802.11 a/b/g/n/ac+ WiGig 802.11ad*4Supports dual-band 2.4/5 GHz + 60GHzUp to 4600Mbps transmission speedSupports MU-MIMO technologyBluetoothBluetooth 4.1sound effect- ESS ESS9018Q2C®- Sonic Studio III Intelligent Sound Management- Supports up to 32-Bit/192kHz playback *5- High quality 120dB stereo playback output 113dBSNR recording input- Support: Jack-detection, Multi-Streaming technology, custom front-panel audio jack function- Front and rear headphone output impedance sensingAudio features:- The rear panel has a fiber optic S/PDIF digital output connection port- Sonic Radar IIIROG Supreme FX8 channel High definition audio codec S1220USB interface8 x USB 3.1 Gen 1 connection ports (8 on the rear panel, blue)AMD X399 chip :2 x USB 2.0 connection ports (2 on the center of the motherboard)2 x USB connection ports (2 located on the rear panel, Type-A + USB Type-C)AMD Ryzen™ Threadripper™ processor:4 x USB 3.1 Gen 1 connection ports (4 on the center of the motherboard)1 x USB 3.1 Gen 2 front connection portASMedia USB 3.1 Gen 2 Controller :®ROG functionality- EZ Plug- DirectKeyOverclocking protection features:- One-click overclockingKeyBot II- ClrCMOS- Power onClear CMOS button- NexFET™ transistorROG RAMDisk memory virtual diskROG RAMCache II- O.C. ProfileROG CloneDriveUSB BIOS Flashback™GameFirst IV- Retry button- Start button- Restart button- PCIe x16 lane switchROG CPU-ZPre-mounted I/O ShieldOverwolfExtreme TweakerROG Extreme OC Kit :- LN2 mode- Secure boot button- Slow start mode- IR3555 PoweIRstage®- Tweakers´ Paradise- 10K black gold capacitor- Powdered superalloy inductorsUEFI BIOS features:- ROG SSD safe removalDIGI+ Digital Power Supply Design :Other featuresASUS features:- Fan Xpert 4 features automatic fan tuning and multiple thermistorsOverclocking protection:- Asus C.P.R. (CPU Parameter Recovery)- Aura programmable strip light headerLiveDash OLED- Aura lighting effects are synchronized with compatible Asus ROG devices- Asus Q-ConnectorEquipped with 5th generation ASUS dual intelligent processor optimized for 5 timesTPUAURA:Player Guardian:- SafeSlot High Strength Security Slot- Aura lighting control- Aura RGB light strip header- AI Suite 3 (Smart Butler 3 Generation)Asus EZ DIY:- Asus CrashFree BIOS 3- Asus EZ Flash 3Asus Q-Design:- 华硕 Q-LED (CPU, DRAM, VGA, Boot Device LED)- Asus Q-DIMMBackplane I/O interface8 x USB 3.1 Gen 1 connectors (blue)1 x ASUS Wi-Fi Module (Wi-Fi 802.11 a/b/g/n/ac+ WiGig 802.11ad and Bluetooth v4.1)1 x USB 3.1 Gen 2 (black) USB Type-C1 x USB 3.1 Gen 2 (red) Type-A5 x LED-Lighting Audio Jack1 x Optical S/PDIF digital audio output1 x Clear CMOS button1 x USB BIOS Flashback™ button1 x LAN (RJ45) interfaceInternal I/O interface1 x PCIe x16 lane switch1 x Safe Boot jumper1 x M.2 Socket 3 slot with M key, 2242/2260/2280 type storage devices (SATA & PCIE SSD supported)1 x U.2 connector*41 x 9 pin Monoblock sensor1 x LN2 Mode switch1 x Start button1 x ReTry header1 x Aura programmable strip light header2 x T_ sensor interfaces2 x 8-pin EATX 8V power connectors2 x Temperature sensor connectors1 x EZ Plug connector (4-pin Molex power connector)1 x USB 3.1 Gen 2 front panel connector2 x USB 3.1 Gen 1 ports extend 4 sets of external USB 3.1 Gen 1 ports1 x USB 2.0 interface expands 2 sets of external USB 2.0 interfaces1 x 5-pin EXT_Fan (expansion fan) slot2 x Aura RGB light strip headers6 x SATA 6Gb/s devices connected to sockets1 x CPU fan power supply slot2 x Chassis fan connectors1 x CPU optional fan connector1 x 24-pin EATX motherboard power supply slot1 x Front Panel Audio Interface (AAFP)1 x Slow Mode switch1 x H_AMP fan header1 x LN2 Mode interface1 x W_PUMP+ interface1 x Restart switch1 x Safe Boot button1 x System panel connector1 x W_IN header1 x W_OUT header1 x W_FLOW headerBIOS128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 6.1, Multi-Chinese BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 Favorites, History,
F12 screenshot and ASUS DRAM SPD (Serial Presence Detect) memory informationManagement softwareWfM 2.0, WOL by PME, PXESize specificationsExpandable ATX form12 inches x 10.9 inches ( 30.5 cm x 27.7 cm style="white-space: normal; background-color: rgb(255, 255, 255); font-family: "Microsoft YaHei"; font-size: medium;"/>
