ATEN CS1922A 2-Port USB 3.0 8K DisplayPort KVMP Switch ATEN CS1922A 2-Port USB 3.0 8K DisplayPort KVMP Switch

International Customers: All electronic products are packaged for sale in the US with US voltage.

Package Contents: CS1922A 2-Port USB 3.0 8K DisplayPort KVMP Switch 2 x DisplayPort Cables (1.5 m/5 ft) 2 x USB Type-A to Type-B Cables (USB 3.0-A to USB 3.0-B; 1.8 m/6 ft) 2 x Microphone Cables (1.8 m/6 ft) 2 x Speaker Cables (1.8 m/6 ft) 1 x Remote Port Selector 1 x Power Adapter 1 x User Instructions

Compatibility: Audio / Video Connectivity: VC986B, VC925 KVM Extenders: CE924, CE980, CE990, KX9970R, KX9970T, CE920 Video Extenders: VE901T, VE901R, VB905, VE901 Video Splitters: VS192 DisplayPort Cables: 2L-7D02DP, 2L-7D03DP-1, 2L-7D03DP, 2L-7D04DP Desktop KVM Switches: CS1924A, CS1942DPA, CS1944DPA

Product Description

This item is brand-new, factory sealed.

ATEN CS1922A 2-Port USB 3.0 8K DisplayPort KVM Switch, Control 2 Computers with 1 Monitor, Keyboard, Mouse, 8K@60Hz, 4K@120Hz, HotKey, Push Button, Remote Port or RS-232 Switching, Cables Included

• Superior video quality up to 7680 4320 @ 60 Hz, 5120 2880 @ 60 Hz and 4096 2160 @ 120 Hz. One USB keyboard and mouse control two DisplayPort computers and share two USB peripherals
• Computer selection via pushbuttons, remote port selector, hotkeys, mouse, and RS-232 commands. DisplayPort 1.4 compliant; HDCP compliant, supports DisplayPort Dual-Mode technology (DP++), and MST (Multi-Stream Transport)
• Independent switching of KVM, USB, and Audio. Supports Console keyboard/mouse emulation/bypass feature
• Power-on detection automatically switches to the next active computer.
• Firmware upgradable. Multiplatform support Windows, Mac, and Linux. Plug and play

• Item Dimensions: 7.87 x 2.87 x 1.69 inches
• Unit Count: 1.0 Count
• Number of Items: 1
• Brand Name: ATEN
• Model: CS1922A-AT-A
• Manufacturer: ATEN
• UPC: 672792017049

ATEN CS1922A 2-Port USB 3.0 8K DisplayPort KVM Switch, Control 2 Computers with 1 monitor, keyboard, mouse, 8K@60Hz, 4K@120Hz, HotKey, push button, remote port or RS-232 switching, Cables included. Product Requirements: Console : A DisplayPort monitor capable of the highest possible resolution, A USB mouse, A USB keyboard, Microphone and speakers, Computers : The following equipment must be available on each computer: One DisplayPort port, A USB Type-A port, Audio ports Operating Systems: Windows 10, Windows 11, macOS 10.15+, Linux, Cables : To guarantee video quality, we recommend using only ATEN DisplayPort KVM cables. Two (CS1922A) or four (CS1924A) cables are provided with this package.

Package Contents:

• CS1922A 2-Port USB 3.0 8K DisplayPort KVMP Switch
• 2 x DisplayPort Cables (1.5 m/5 ft)
• 2 x USB Type-A to Type-B Cables (USB 3.0-A to USB 3.0-B; 1.8 m/6 ft)
• 2 x Microphone Cables (1.8 m/6 ft)
• 2 x Speaker Cables (1.8 m/6 ft)
• 1 x Remote Port Selector
• 1 x Power Adapter
• 1 x User Instructions

SpecificationPower DescriptionInput Voltage Range12 V DCPhysical CharacteristicsWeight (Approximate)1.04 Warranty3 YearInterfaces/PortsNumber of USB Ports6Network (RJ-45)YesNumber of DisplayPorts3USBYesDisplayPortYesUSB 2.0YesNumber of Network (RJ-45) Ports1USB Standard

• USB 2.0
• USB 3.0

VideoMaximum Video Resolution7680 x 4320Graphic Mode8KGeneral InformationBrand NameATENMarketing Information Built on ATEN's enterprise-grade design heritage, the CS1922A belongs to ATEN's first KVM switch series with 8K support, delivering professional-grade performance and reliable multi-computer control from a single console. Ultra-High Resolution for Versatile Professional Applications The CS1922A delivers up to 8K@60 Hz and 4K@120 Hz, providing precise, clear visuals for demanding tasks. It enables users to control multiple computers from a single console, supporting efficient multitasking and high-resolution workflows while keeping the workspace clean and organized. Multi-Display Expansion and Broad Display Compatibility Daisy-chaining further allows multi-display setups using a single keyboard and mouse, streamlining multi-screen workflows and enhancing productivity for complex tasks. With DisplayPort Dual-Mode (DP++) support, the switch can connect to HDMI or DVI displays via compatible adapters, expanding compatibility with a wide range of monitors. Flexible and Intuitive Switching for Efficient Workflows Multiple switching methods, including front panel pushbuttons, a remote port selector, hotkeys, mouse switching, and RS-232 commands, allow users to control connected computers seamlessly. This flexibility enables fast, efficient workflow management tailored to individual preferences, ensuring smooth transitions between multiple systems. Efficient Peripheral Sharing and Easy Installation The integrated USB 3.1 Gen 1 hub provides 5 Gbps data transfer speeds, enabling fast sharing of peripherals between connected computers. All required DisplayPort and USB cables, along with a power adapter, are included for quick, plug-and-play setup, helping users maintain a clean, organized, and fully functional workspace from the start. Product TypeKVM SwitchboxProduct Name2-Port USB 3.0 8K DisplayPort KVMP Switch (Cables included)ManufacturerATEN Technology, IncManufacturer Part NumberCS1922AProduct ModelCS1922ATitleProduct TitleATEN 2-Port USB 3.0 8K DisplayPort KVMP Switch [Cables included] (CS1922A)Technical InformationNumber of Computers Supported2Maximum Data Transfer Rate640 MB/sFeaturesLED IndicatorConnectivity TechnologyWiredEnvironmental ConditionsMaximum Operating Temperature122°F (50°C)Minimum Operating Temperature32°F (0°C) Shipping
