Broadcom LSI 9306-24i 12Gbps SAS-3 PCIe x8 HBA P16 IT mode
Listed for sale is a Broadcom LSI 9306-24i HBA SAS controller card. It is fully updated to Avago / LSI 9305-24i IT (Initiator Target) mode firmware version P16 (specifically 16.00.12.00). I also flashed the LSI/Avago MPTSAS3 BIOS ROM version 08.37.02.00 and UEFI 18.00.03.00 so that it is easier to access the controller's ROM without booting an OS.
- LSI IT mode firmware version P16 (16.00.12.00)
- MPTSAS3 BIOS ROM flashed version 08.37.02.00
- MPTSAS3 UEFI ROM flashed version 18.00.03.00
- Original SAS address preserved in flash
- Original Board Tracer Number preserved in flash
- Original Board Assembly preserved in flash
- BOTH full profile and low profile brackets included (top connector may not fit cable when used in low profile slot)
- PCIe 3.0 x8
- Requires SFF-8654 8i connector cables which are not included. If you're interested in a combo kit with SATA forward breakout cables, see my other listing. This listing is for HBA card only.
These are based on the LSI SAS3224 SAS controller chipset and support 12Gbps SAS-3 storage devices. It uses a PCI-E 3.0 connection with x8 lanes. The controller has 3 SFF-8654 8i connectors, each carrying 8x 12Gbps SAS lanes for a total of 24 SAS lanes.CAUTION#1: Please note this card is a high performance card and runs hot. You must install it with plenty of airflow over its heatsink. Improper cooling can cause failure and poor reliability.
CAUTION#2: The required cables for this card have limited selection. Please be sure you are able to source the cables you need before purchase.
These cards are fully tested in my Supermicro server running ZFS on Linux (ZoL), but this setup is also ideal for other ZFS setups, FreeNAS, unRAID, Proxmox VE, etc. I have fully tested them using all 16 SAS lanes.
Not exactly the HBA / IT mode adapter you were looking for? Check out the HBA section at my store here.
Feel free to ask any questions.
