Enterprise Testing Conditions
Threat Prevention (Mbps)1 2,000
Next Generation Firewall2 5,000
IPS Throughput (Mbps) 5,500
Firewall Throughput (Mbps) 7,500
RFC 3511, 2544, 2647, 1242 Performance (LAB)
Firewall 1518 Byte UDP Packets (Mbps) 17,000
VPN AES-128 Throughput(Mbps) 4,000
Connections per Second 66,000
Concurennt Connections 2,400,000
Software
Security Firewall,VPN, User Awareness, QoS, Application Control, URL Filtering, IPS, Anti-Bot,Antivirus, Anti-Spam and SandBlast Threat Emulation (sandboxing)
Unicast, Multicast Routing OSPFv2,BGPv4 and 4++, RIP, IGMP
Mobile Access License (Users) 500 remote SNX or Mobile VPN client users
Hardware
WAN Port 2x10/100/1000Base-T RJ-45 / 1000BaseF SFP ports (transceiver not included) *WAN2support in future SW release
DMZ Port 1x10GbE Base-T RJ-45 / 10GbE SFP+ (transceiver not included)
LAN Switch Ports 2x2.5GbE Base-T RJ-45 plus 16x 10/100/1000Base-T RJ-45 ports
Management Ports 1x10/100/1000Base-T RJ-45 port *MGMT support in future SW release
Console Ports 1xUSB-C and 1x RJ-45 console port
USB Port 2xUSB 3.0 ports
Storage 256GB SSD and Micro-SD slot with 32 and 64 GB card options
eMMC 32 GB
MTBF 15.64 years @25ºC
Dimensions
Enclosure 1U
Dimensions (W x D x H) 430x 300 x 44.2 mm (16.93 x 11.8 x 1.74 in.)
Weight 6.76 kg (14.9lbs.)
Environment
Operating / Storage 0ºC~ 40ºC / -45ºC ~ 60ºC (5~95%, non-condensing)
Power Requirements
AC Input 110– 240VAC, 50 – 60 Hz
Power Supply Rating tworedundant 150W power supplies
Power Consumption (Max) 93.6W
Heat Dissipation 319.3
Certifications
Safety | Emissions | Environment UL/c-UL 62368-1 , IEC 62368-1 CB / EMC, EMI EN55024,EN55032 Class B, VCCI, AS, NZS CISPR 32, IC ICES 03, FCC: Part 15 Class B /RoHS, REACH, WEEE
