24-Port Ethernet L3 Switch, 20 x 10Gb SFP+, with 4 x 25Gb SFP28 and 2 x 40Gb QSFP+, PicOS®, Support MLAG, Broadcom Chip

The S5860-20SQ is a next-generation L3 switch featuring Broadcom chip, with 760 Gbps switching capacity and 565 Mpps forwarding performance. It features 20× 1/10G downlinks, 4× 10/25G SFP28 uplinks, and 2× 40G QSFP+ uplinks (4× 10G breakout) in a 1U form factor, with redundant hot-swappable power supplies and smart fans for reliability.
RunningPicOS®with a perpetual license, the switch supports MLAG, SSH, ACLs, OSPF, PBR, and sFlow without extra licensing and includes five years of hardware and software support. Ideal for large campus distributions, SMB cores, and low-density data center ToR deployments, it delivers enterprise-grade performance and flexibility.
The switch is managed by theAmpCon-Campus management platform, offering Day 0 to Day 2+ automated lifecycle management with Zero Touch Provisioning (ZTP), topology discovery, and real-time telemetry. AmpCon-Campus automates workflows, simplifies operations, and enhances visibility into the performance of connected devices.

SpecificationsPorts20x 1G/10G SFP+ | 4x 10G/25G SFP28, 2x 40G QSFP+ (split to 4x 10G)Operating SystemPicOS®Switch ChipBroadcom BCM56170Switching Capacity380 Gbps (unidirectional)/760 Gbps (offerirectional)Power Supplies2 (1+1 Redundancy) Hot-swappableForwarding Rate565 MppsFans2x Hot-swappable Fans, Front-to-BackPacket Buffer4MBDimensions (HxWxD)1.72''x17.32''x12.99'' (43.6x440x330mm)Traffic MonitoringsFlowForm Factor1RUQoS Queues8 unicastWeight10.14 lbs (4.6kg)Jumbo Frame9,216Input Voltage100V-240VAC, 50-60HzMAC Address32,768Input Current3A (MAX) at 90VIPv4/IPv6 Routes16K/8KMax. Power Consumption85WDRAM1GBOperating Temperature0 to 50ºC (32 to 122°F)Flash Memory1GB
