• GA-7PESH1(rev. 1.1)
  • Intel®Xeon®processor E5-2600 & E5-2600 V2 product families
  • 16 x RDIMM/UDIMM ECC DIMM slots
  • 2 x GbE LAN ports (Intel®I350-AM2)
  • 2 x SATA III 6Gb/s + 4 x SATA II 3Gb/s
  • 8 x SAS 6Gb/s
  • Aspeed®AST2300 remote management controller

•

• High Performance Computing Board
• GIGABYTE introduces its latest high end server motherboard based on Intel®’s brand new Xeon®processor E5-2600 product family and the Intel®C602 chipset. This dual socket motherboard is addressed to enterprise requirements for top performance computing in server / datacenter environments.
• Intel®Xeon®Processor E5-2600 V2 Product FamilyFinally, virtualization applications will benefit from increased performance thanks to the Advanced Programmable Interrupt Controller (APIC) technology, and more security features are included in the mix as well, such as the Intel® Platform Protection Technology with OS Guard, and Intel® Data Protection Technology with Secure Key.
• Deployable through a simple BIOS update, the support of the Intel Xeon processors E5-2600 V2 product family delivers the benefits of the 22nm tri-gate process technology to the high end server industry. Those benefits include, among others, higher frequencies, higher core counts (up to 12 cores / 24 threads) and larger last-level caches, but especially a much more varied mix of core/frequencies with notably the introduction of a new dual socket workstation segment. This new die shrink also allows for overall energy efficiency increase, with up to 30% average decrease in idle power consumption.
• Faster Memory, With GIGABYTE Only
• Always eager to go beyond the industry standards, GIGABYTE’s engineering has enabled through its capabilities in design, PCB layout and BIOS fine-tuning the support of 1866 MHz memory frequency running at higher DIMM population (8 DIMMs per socket) where Intel’s standard and the rest of the market’s products will typically operate memory speed downgrade and support 1866 MHz at lower DIMM population only (4 DIMMs per socket). GIGABYTE therefore offers at launch on its 2011 socket based products this unique feature which will benefit to high density and memory intensive applications, such as high frequency trading, telecommunication networks, mobile data transfers, and so on.
• Digital Power ControlThe GA-7PESH1 includes GIGABYTE’s digital PWM controllers, guaranteeing a dynamic power supply to the processors and memory with an ultra-fast response time. Built with advanced calibration tools, they allow to get the purest and most efficient electrical supply to date. When the CPU workloads vary in function of the applications running, the Intel Turbo Boost Technology will do a dynamic overclock of the CPU cores. This is where the digital PWMs outshine the previous analog solutions. This way the CPUs operations are much more stable, and the overall reliability of the system is greatly improved.
• Support of PCIe Generation 3.0
• With the support of the latest PCI Express Gen.3.0 technology directly on the CPU, the GA-7PESH1 is fully configured to provide users with dramatically reduced latency and improved data bandwidth to get the most out of its expansion accessories. Moreover, it is built with a comprehensive variety of PCIe connectors to provide the most flexible expansion platform to the user.
• SATA 3.0 & SAS 3.0 Revisions
• The GA-7PESH1 can receive up to two SATA 3.0 devices and up to eight additional SAS or SATA 6Gbs devices through its onboard LSI SAS solution to benefit from today’s best data transfer rates.
• VMware ReadyThe VMware Ready logo certifies that this product addresses VMware's specific criteria in terms of integration and compatibility, and that it is ready to execute mission-critical applications and operations.
• The VMware Ready program allows customers to quickly identify products and solutions from VMware's partners, which are optimized for VMware vSphere.
• Red Hat Certified HardwareGIGABYTE has certified the GA-7PESH1 with Red Hat Enterprise Linux to provide its customers with the confidence of knowing that their hardware systems are supported by Red Hat when they run Red Hat Enterprise Linux.

* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.

• Form FactorE-ATX / SSI EEB
  305W x 330D (mm)
• CPUSupports:
  • Intel®Xeon®E5-2600 V2 processors
  • Intel®Xeon®E5-1600 V2 processors (single CPU configuration only)
  • Intel®Xeon®E5-2600 processors
  • Intel®Xeon®E5-1600 processors (single CPU configuration only)
• Socket2 x LGA 2011
  Mounting pitch: square ILM (80x80mm)
  Max. length of M4 screw threads: 3.7mm
  Screws longer than 3.7mm might damage the motherboard
• ChipsetIntel®C602
• Memory16 x DIMM slots
  Quad channel memory architecture
  ECC & non-ECC UDIMM/RDIMM modules supported
  Single and dual rank UDIMM modules up to 8GB supported
  Single, dual and quad rank RDIMM modules up to 32GB supported
  1.35V modules: 1066/1333/(1600*) MHz
  1.5V modules: 1066/1333/1600/(1866*) MHz

  *Supported by Intel®Xeon®E5-2600 V2 processors only

  Download the detailed memory configuration table for the E5-1600/2600 V2 processors
  Download the detailed memory configuration table for the E5-1600/2600 processors
• LAN2 x GbE LAN ports (Intel®I350-AM2)
  1 x 10/100 management LAN
• VideoIntegrated in Aspeed®AST2300
  2D Video Graphic Adapter with PCIe bus interface
  1920x1200@60Hz 32bpp
• Audio-
• SAS2 x Mini-SAS (for 8 x SAS 6Gb/s ports)
  1 x Mini-SAS (for 4 x SATA II 3Gb/s ports)
• SATA2 x SATA III 6Gb/s ports
• RAIDIntel®SATA RAID 0/1/5/10
  LSI®SAS2008 RAID 0/1/1E/10
• Expansion Slots1 x PCIe x16 (Gen3 x16 bus) slot
  1 x PCIe x16 (Gen3 x8 bus) slot
  2 x PCIe x8 (Gen3 x4 bus) slots
  1 x PCIe x4 (Gen2 x1 bus) slot
• Internal I/O2 x 8-pin ATX 12V power connectors
  1 x 24-pin ATX main power connector
  1 x PMBus connector
  2 x CPU fan headers
  2 x System fan headers
  1 x SATA SGPIO connector
  1 x Flash descriptor security jumper
  1 x HDD back plane connector
  1 x USB 2.0 header
  1 x Front panel header
  1 x IPMB connector
  1 x TPM header
  1 x Patsburg-A SKU select connector
  1 x Clear CMOS jumper
  1 x BIOS write protect jumper
  1 x ME recovery jumper
  1 x Chassis intrusion jumper
  1 x Clear password jumper
  1 x BIOS recovery jumper
  2 x SATA port DOM support jumpers
• Rear I/O4 x USB 2.0
  1 x VGA
  1 x Serial
  3 x RJ45
  1 x ID button with LED
• TPM1 x TPM header
• OS SupportedWindows Server 2008 SP2 (x86)
  Windows Server 2008 R2 (x64)
  Windows Vista SP2 (x86/x64)

  Red Hat Enterprise Linux 5.6 (x86/x64)
  Red Hat Enterprise Linux 6.1 (x86/x64)

  SUSE Linux Enterprise Server 11.1 (x86/x64)

  VMware ESXi 5.0 / 5.1 / 5.1 U1 / 5.1 U2
• Board ManagementAspeed®AST2300 management controller
  Avocent®MergePoint IPMI 2.0 web interface:

  • Network settings
  • Network security settings
  • Users control
  • Services settings
  • IPMI settings
  • Sessions control
  • LDAP settings
  • Power control
  • Voltages, fans and temperatures monitoring
  • System event log
  • Events management (platform events, trap settings, email settings)
  • Serial Over LAN
  • vKVM & vMedia (launch, configuration)
• PSU Connectors1 x 24-pin ATX main power connector
  2 x 8-pin ATX 12V power connectors
• Retail Packaging Content1 x Driver CD
  1 x I/O shield
  2 x SATA II 3Gb/s cables (500mm)
• Reference NumbersRetail: 9M7PESH1MS-00
  Bulk: 9M7PESH1NS-00

* The entire materials provided herein are for reference only. GIGABYTE reserves the right to modify or revise the content at anytime without prior notice.
* Advertised performance is based on maximum theoretical interface values from respective Chipset vendors or organization who defined the interface specification. Actual performance may vary by system configuration.
* All trademarks and logos are the properties of their respective holders.
* Due to standard PC architecture, a certain amount of memory is reserved for system usage and therefore the actual memory size is less than the stated amount.
* Product configuration may vary based on local distribution.
* GIGABYTE partners with a variety of open-source software vendors and communities to ensure compatibility with its hardware platforms. However, GIGABYTE cannot guarantee continued support from these third-parties, if they decide to stop supporting the software. In these cases, any resultant technical and support issues should be referred to the relevant third-party vendor.Ship to aConfirmed physical addressonly,NO P.O.Box
