Intel 256GB NVMe PCIe Gen3 x4 Compact M.2 2242 Client Solid State Drive

Lenovo FRU/PN: SSS0L25128 | Intel Model: SSDPEKKF256G8L | Series: Pro 7600p

The Intel SSS0L25128 (SSDPEKKF256G8L) is a high-performance, compact NVMe solid-state drive custom-tailored for specialized client computing setups and ultra-thin laptop configurations. Built on the professional-tier Intel Pro 7600p series platform, this drive uses a rare, space-saving M.2 2242 (42mm) form factor. Running over a full-bandwidth PCIe Gen3 x4 interface and featuring Intel’s advanced 3D TLC NAND, it is engineered to deliver desktop-class storage speeds, corporate hardware security features, and ultra-low power consumption for space-constrained computing builds.

• Capacity: 💾 256 GB

• Interface: ⚡ PCIe Gen3 x4 / NVMe 1.3

• Form Factor: 📏 M.2 2242 (Compact 42mm length)

• NAND Flash Type: 🧠 Intel 3D TLC NAND

• Sequential Read: 🏎️ Up to 3,210 MB/s

• Sequential Write: ✍️ Up to 1,315 MB/s

• Random Read/Write: 📉 Up to 205,000 / 265,000 IOPS

• Security & Device Management: 🔐 Intel vPro™ Technology, TCG Opal 2.0, AES 256-bit Self-Encryption (SED)

• Lenovo Validated OEM Architecture: Pre-flashed with stable Lenovo OEM firmware and labeled under internal system part number SSS0L25128. This guarantees native, drop-in compatibility across supported Lenovo ThinkPad and ThinkCentre units without triggering white-list component validation boot warnings.

• Full PCIe Gen3 x4 Bandwidth: Unlike many smaller 2242 form-factor drives that run on slower Gen3 x2 lanes, this Intel module leverages a full 4-lane pipeline. It achieves remarkable sequential read speeds of up to 3,210 MB/s, delivering incredibly fast application load times and quick file migrations.

• Thermal and Electrical Optimization: Built with mobile computing efficiency in mind. The integrated Intel storage controller actively regulates power consumption states to extend portable laptop battery runtime while managing temperatures intelligently within tight device compartments.

• Target Systems:

  • Lenovo ThinkPads & Desktops: Native fit for various Lenovo ThinkPad laptops (often utilized as primary storage or secondary caching in WWAN/M.2 extension slots) and ThinkCentre Tiny mini PCs.

  • Small Form Factor Electronics: Excellent choice for compact handheld consoles, NUC modules, and industrial embedded PC boards featuring a 42mm M.2 storage slot.

• Ideal Workloads:

  • Primary Operating System Volume: Highly responsive primary boot partition for Windows 10/11, ChromeOS, or customized Linux distributions.

  • ⚠️ Physical Size & Mounting Requirement: This drive features a physical M.2 2242 form factor (42mm long). While it will function perfectly in a standard, longer M.2 2280 (80mm) slot, you will need a structural extension adapter bracket or an appropriately positioned motherboard standoff screw hole to safely clamp it down.

    ⚠️ NVMe Interface Check: Ensure your host device's internal M.2 port is actively wired for an NVMe PCIe interface link. This drive utilizes an "M-Key" edge connector scheme and will not be recognized if installed inside older, strictly legacy SATA-only M.2 bays.

    The Intel SSS0L25128 (SSDPEKKF256G8L) pairs full PCIe Gen3 x4 throughput and corporate vPro hardware protection with a unique, compact M.2 2242 framework.
