Leviton SPLCH-12BL HDX 12-Fiber OS2 LC Shuttered Splice Module Click Thumbnails to EnlargeDESCRIPTION
Leviton SPLCH-12BLSplice Module; OS2 Fiber; 12 Fiber; LC Shuttered Connector 1; Blue Housing; Polycarbonate Housing; 0.25 dB Insertion Loss; >55 dB Return Loss; Dimensions: WxHxD: 3.8 x 6.24 x 0.52 in.
APPLICATION
HDX LC & MTP Splice Modules protect and organize heatshrink fusion spliced fibers (up to 12 or 36 fibers) inside afiber enclosure or panel. The modular design enables fasterfield splicing and simple management of pigtails within thehousing. Splice modules eliminate the need for individualsplice trays within a fiber enclosure and provide optimalorganization and slack management of fibers. Typicalapplications include Wide Area Networks (WAN), campuses,high-count riser buildings, government installations, datacenters, and central offices.
FEATURES
• Modules integrate fiber adapter bulkhead (12 or 36 fibers)and splice holders, eliminating need of splice trays
• Offered in single-mode (OS2) UPC, APC, laser-optimizedmultimode (OM4), and SWDM multimode (OM5) fiber typesin LC or MTP connectivity
• MTP splice module offered in pinned or unpinned
• No proprietary tool or fixture required for fusion splicing
• Patented 12-fiber color-coded pigtail assembly offerscapability to fusion splice individual or mass fusionribbon fibers
• Optional patented internal shutters on LC adapterseliminate the need for dust plugs to reduce waste, speedup deployment, and ensure safer installations
• Modular design allows for easy maintenance of individualspliced fiber and scaling up without impacting existing fibers
• Accessory kit includes 40 mm heat-shrink individual splicesleeves, ribbon splice sleeve, braided mesh sleeve,and tie wraps
PRODUCT SPECIFICATIONSPart NumberSPLCH-12BLProduct TypeSplice ModuleConnector 1 TypeLC ShutteredFiber TypeOS2Fiber Count12DimensionsW x H x D: 3.8 x 6.24 x 0.52 inHousing MaterialPolycarbonateInsertion Loss0.25 dBReturn Loss>55 dBHousing ColorBlueColorBlueWeight (lbs)0.65
