MSI PRO B760M-VC WiFi (Bulk) – Motherboard Specifications

Part number: B760MPROVCWIFI-B | UPC: 824142364543 | Compiled from retailer and product listings. Verify against msi.com before purchase.

General

Brand / Series

MSI PRO series

Model

B760M-VC WIFI (Bulk package)

Form factor

Micro-ATX, 9.6" × 9.6"

Country of years

Processor & B760

Supported CPUs

Intel Core, Pentium Gold, Celeron (12th, 13th, 14th Gen)

Processor DIMM / UDIMM

Slots

4

Maximum capacity

256 GB (some listings state 192 GB)

Speed (JEDEC / POR)

Up to 4800 MHz

Overclock speeds

6200+ MHz (1DPC 1R); 5200+ MHz (1DPC 2R); 4000+ MHz (2DPC)

Channels

Dual channel

Expansion

PCIe x16 slots

4 total: 1 × PCIe 4.0 x16 (CPU), 3 × PCIe 3.0 x1 (chipset)

PCIe standard

PCIe 4.0 and 3.0

Storage

SATA

6 ports (SATA 6Gb/s)

M.2

2 slots (one listed as PCIe Gen 4 x4)

RAID

Levels 0, 1, 5, 10

Networking

Wired LAN

Realtek 8125BG 2.5 GbE (2.5 Gigabit Ethernet)

Wireless LAN

Wi-Fi 6E per Best Buy; other listings: IEEE 802.11 external ports

8

USB 3.2 Gen 1 Type-A

4

USB 3.2 Gen 2 Type-A

1

USB 3.2 Gen 2 Type-C

1

USB 2.0

2

Onboard USB headers

7 total (4 × USB 2.0)

Video & Audio

Video outputs

HDMI and DisplayPort (CPU-dependent graphics)

Audio

7.1 channels

Power & Build

CPU power

12+1 phase Duet Rail design; 8-pin + 4-pin CPU connectors

Thermal

MOSFET thermal pads rated 7 W/mK

PCB

6-layer, 2 oz copper
