Panduit NK6X88MYL Cat-6A Punchdown Keystone Jack Module UTP RJ45 YellowClick Thumbnails to EnlargeDESCRIPTION

• The NetKey Cat 6A UTP RJ45 Punchdown Keystone Jack Module is designed to terminate 4-pair, 22–26 AWG twisted pair cable. Each module is 100% factory tested to exceed industry standard performance requirements. Contacts are plated with 50 microinches of gold for superior performance. Jacks are individually serialized for traceability and are compatible with keystone interfaces such as NetKey Faceplates, Modular Patch Panels, and Surface Mount Boxes. The jack module is Yellow.

STANDARDS

• Exceeds Channel and Component Requirements of ANSI/TIA-568.2-D and ISO 11801 Standards for the Respective Category, Meets IEC 60603-7, Supports 2500 Connection Cycles with IEEE 802.3af / 802.3at and 802.3bt Type 3 and Type 4, UL 1863 and UL 2043 and RoHS Compliant.

PRODUCT SPECIFICATIONSProduct TypeJack Module
Performance LevelCategory 6AConnector Type
Jack Module - Standard
Termination StylePunchdownBody MaterialPolycarbonateContact MaterialPlated Phosphor BronzeModule TypeKeystoneWiring Scheme
T568A/T568BShield Type
Unshielded (UTP)ColorYellowOverall Length (inch)1.16Overall Width(inch)0.65Overall Depth(inch)1.16Overall Height(inch)0.9
