￭ Support standard Flex ATX form factor
￭ High efficiency with 80 PLUS Gold certification
￭ 350W continuous power output at 40℃ operating temperature rated for 24/7 operation
￭ Class-leading single +12V rail
￭ Support PCIe 6pin connector
￭ Active PFC
Model No.
SST-FX350-G
Max. DC Output
350W
Power density
707W per liter
Load Range
+3.3V +5V +12V1 +12V2 +5VSB -12V
Max.(Amps)
17A 14A 29.17A / 2.5A 0.3A
Peak (Amps)
/ / / / / /
Min.(Amps)
0A 0A 0A 0A 0A 0A
Range (%)
±3% ±3% ±3% / ±10% ±10%
Line Reg.(%)
±1% ±1% ±1% / ±1% ±1%
Ripple(mVp-p)
50mV 50mV 120mV / 50mV 120mV
Color
Black（Lead-Free Paint）
Combined +3.3V & +5V
90W
Combined +12V
350W
Input Voltage
90 ~ 264 Vrms
Input Frequency Range
47Hz ~ 63Hz
PFC
Active PFC (PF>0.9 at full load)
Efficiency
87% ~ 90% at 20% ~ 100% loading
MTBF
100,000 hours
Operating temperature
0°C ~ 40°C
Protection
Over Power Protection
Over Voltage Protection
Short Circuit Protection
Connectors
1 x 24 / 20-Pin motherboard connector（350mm）
1 x 8 / 4-Pin EPS / ATX 12V connector（450mm）
1 x 6-Pin PCIe connector（350mm）
3 x SATA connector（350mm / 150mm / 150mm）
2 x 4-Pin Peripheral connector（350mm / 150mm）
1 x 4-Pin Floppy adapter connector（350mm / 150mm / 150mm）
Cooling System
Single 40mm silent fan
Form factor Flex ATX
Noise Level
20 dBA minimum
Dimension
81.5 mm (W) x 40.5mm (H) x 150 mm (D)
3.21" (W) x 1.59" (H) x 5.91" (D)
Weight
0.96 kg
Certification
80 PLUS Gold
Other
Compatible with ATX12V v2.4
