ResolutionWXGA
The Steelcase PJ930 offers an impressive 3000 lumens DLP WXGA 1280 x 800 native resolution, and supports video inputs up to 1080p. Providing users with crisp clear image.
Throw DistanceUltra Short Throw
The PJ930 offers an ultra short throw range with a throw ratio of 0.35. This minimizes the distance between the projector and board.
Model: PJ930 SpecificationsPanel Size / resolution0.65" WXGA, S450, DDP4421TechnologyDLPThrow ratioUltra short throw 0.35Lumens3000 (standard), 2450 (eco)Contrast ratio2300:1ResolutionWXGA, XGAAspect ratios16:10 (Native), 4:3, 16:9Lamp life5,000 hours (standard), 8,000 hours (eco)Power buttonYes3D ReadyYesSpeaker(s)10W (two speakers)Color wheel6 segment (RGBCYW)Noise level33dB (standard), 29dB (eco)Power supplyAC input 100~240, +/- 10% voltagePower consumption290W (standard), 260W (eco), <0.5W (standby)LED IndicatorPower LED: Green, Temp LED: Red, Lamp LED: AmberInput signalData: VESA Standard
HDTV: 1080i / 720p / 1080p
DTV: 4801i / 480p
Video: NTSC/NTSC 4.43, PAL B/G/H/I, SECAMTerminal I/OComputer in: VGA (2), Display Port
Computer out: VGA
Video in: Video, S-Video, HDMI (1.4)
Audio in: Mini jack, RCA R/L
Audio out: Mini jack
Microphone: Phone jackControl I/ONetwork management: RJ45
USB (upgrades)
Room control: RS232TemperatureNon-operating: -10 ~ 60 degree C
Operating: 5 ~ 40 degree CAltitudeNon-operating: Sea level ~ 30,000 FT
Operating: Sea level ~ 10,000 FT
@23 degree CHumidityNon-operating: 5% ~ 95% (no condensation)
Operating: 10% ~ 85% (no condensation)AccessoriesPower cord: 4.5m
VGA cable: 4.5m
Remote control
User Manual (CD)Lamp replacementWhile mounted Part No. 23354001SRRemote control replacementPart No. 23354101SRKensington Lock SlotYes
