Zombie Components LLC Sylmar, California Supermicro SBA-7121M-T1 Processor Blade with AOC-IBH-002 SBA-7121M-T1 · AOC-IBH-002 2x AMD Opteron OS2374PAL4DGI · 16GB DDR2 · 4x DDR 20Gbps InfiniBand mezzanine
Supermicro SBA-7121M-T1 processor blade (black) on the Super BHDME motherboard, with two AMD Opteron processors, 16GB of DDR2 memory, and an AOC-IBH-002 single-port 4x DDR 20Gbps InfiniBand mezzanine HCA (Mellanox InfiniHost III Lx chip).
The photos show two copper CPU heatsinks, eight DIMM sockets, the AOC-IBH-002 mezzanine card, an MCP-280-KVM1 board behind the front KVM connector, two drive bays, and the two rear backplane connectors. Six units are available; quantity is set in the listing.
Condition
Used: 60 day money back guarantee.
Specifications bladeMotherboardSuper BHDMEProcessors2x AMD Opteron OS2374PAL4DGIMemory installed16GBMemory typeDDR2 800/667/533MHz buffered (registered) ECC SDRAMInfiniBandAOC-IBH-002 mezzanine HCA, single port 4x DDR 20Gbps, Mellanox InfiniHost III LxFront panelPower button, KVM button, status LEDs, KVM connector, 2 drive bays Configuration SBA-7121M-T1Processor Blade SBA-7121M-T1 (Black)AOC-IBH-002 InfiniBand Single port 4x DDR 20Gbps Mezzanine HCA
(Mellanox InfiniHost III Lx chip) Motherboard
Motherboard
Super BHDME Processor and chipset Processor/ChipsetCPUDual 1207-pin Socket FSupports up to two Six-Core / Quad-Core AMD Opteron™ 2000 Series processorsHT3.0 Link supportChipsetnVidia MCP55 Pro System memory System MemoryMemory CapacityEight 240-pin DIMM socketsSupports up to 64 GB DDR2 800/667/533 MHz memorySingle or Dual (recommended) channel memory supportFor Quad CPUs: Recommended that memory be populated equally in adjacent memory banksMemory TypeDDR2 800/667/533MHz buffered (registered) ECC SDRAM 72-bit, 240-pin gold-plated DIMMsDIMM Sizes512MB, 1GB, 2GB, 4GB, 8GBMemory Voltage1.8V onlyError DetectionCorrects single-bit errorsDetects double-bit errors (using ECC memory) On-board devices On-Board DevicesInfiniband Support4x DDR (20Gb/s) InfinibandSATAnVidia MCP55 Pro SATA2 3.0Gbps Controller2 SATAII PortsIPMISupport for Intelligent Platform Management Interface (IPMI) v.2.0 via Chassis Management Module (CMM)Network ControllersIntel® 82571EB Dual-port Gigabit Ethernet ControllerSuper I/OWinbond 83627HFVGAATI ES1000 Graphics Controller System BIOS System BIOSBIOS Type8Mb Flash EEPROM with AMI® BIOSSST 49LF080A BIOS ChipBIOS FeaturesPlug and Play (PnP)DMI 2.3PCI 2.2ACPI 2.0USB Keyboard SupportSMBIOS 2.3 Included
One Supermicro SBA-7121M-T1 blade with two Opteron processors and heatsinks, 16GB RAM and the AOC-IBH-002 InfiniBand mezzanine installed, per unit purchased, as shown in the photos.
Not included:
Blade enclosure
Chassis management module (CMM)
Hard drives
Quality control
Where possible, electronics are tested. The value of an item determines the effort put into testing; items not specifically tested in detail are visually inspected and reviewed for operational status. Any exceptional wear is noted in the description. Most items are covered by a money-back guarantee.
Shipping
Orders may take up to 3 business days to ship from payment; weekends are not counted. If you need faster service, contact us before ordering so we can adjust priorities. We reserve the right to change the selected shipping method to an equivalent or better service that fits the item.
We ship worldwide. USPS may not be an acceptable choice for international shipping due to size, weight, and export documentation restrictions; you may be asked to select FedEx, UPS, or DHL at a higher price. Confirm your shipping choice with us before ordering if in doubt.
Export compliance. Our products are subject to the U.S. Export Administration Regulations (EAR), overseen by the Bureau of Industry and Security (BIS) and the U.S. Census Bureau. We do not ship to Country Group E. Determining the Export Control Classification Number (ECCN) can take up to 30 days; where an export license is required, licensing can take a further 30-90 days. For international orders we require a written statement of the ultimate end user, the intended end use of each product, and the buyer's agreement to comply with the EAR. You will receive an email with the documentation; the order cannot be processed until it is complete.
Returns, and money-back guarantee
This listing carries a 60 day money back guarantee: return your purchase for any reason within 60 days for a full refund or exchange. Returned items must be in the condition received and in the original packaging.
All items are guaranteed to be as described. Any item not as described can be returned at our expense for a full refund, regardless of any as-is marking.
If you are dissatisfied for any reason, contact us first and give us a chance to work things out; if we cannot fix it, you receive 100% of your purchase price back.
