FEATURES:

· Compliant with PCI Express specification Rev. 2.0

· Compatible with industrial standard 16C450.16C550.16C650.16C750.16C950 UART

· Data transfer rate up to 115200bps on each port

· Support on chip 256-Byte depth FIFO in transmit, receive path of each serial port

· Support 5-6-7-8-bit serial format, 1 or 2 Stop bit mode

· Support MODEM signal CTS, DSR, RI, DCD, DTR, RTS can be converted to RS232 level

· Odd, Even, No parity, space 0 and mark 1 etc.

· Low Profile Bracket included for slim size desktop PC installation

SPECIFICATIONS:

Standard:

BUS Type:

PCI Express Rev. 2.0 (PCIe x1)

Interface:

4 x DB9 RS232 Serial Port

Chipset:

ASIX AX99100

Data Transfer Rate:

115200bps/port

Compatible PC:

Full/Slim Size Desktop PC

OTHERS:

Certification:

FCC, CE, RoHS

Package Content:

XM-PEX4S Controller Card

DB9 Cable

Low Profile Bracket

CD Driver Disk

User Guide

Supported OS:

Windows XP/Vista/7/8/8.1/10 (32&64Bit)

Linux Kernel 4.x/3.x/2.6x

Environment:

Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
