Gigabyte Technology MW83RP0 Motherboard Gigabyte Technology MW83RP0 Motherboard
International Customers: All electronic products are packaged for sale in the US with US voltage.
This item is brand-new, factory sealed.
MW83-RP0 Rev. 1.x
Motherboard - Intel Xeon W-3400/2400 - CEB UP
Single Intel Xeon W-3400/2400* Processors
8-Channel DDR5 RDIMM, 8 x DIMMs
Intel W790 chipset
2 x 10Gb/s LAN ports via Intel X710-AT2
2 x SlimSAS connectors for 8 x SATA 6Gb/s
2 x M.2 slots with PCIe Gen4 x4 interface
5 x PCIe Gen5 x16 expansion slots
2 x PCIe Gen4 x16 expansion slots
Intel Xeon W-3400 & W-2400 Sapphire Rapids Platform
New Expert 1S and Mainstream Workstation Solutions
Compute heavy workloads rely on the best and latest CPU technology to deliver excellent performance while the new Xeon line of processors with Intel spans from high-end to more affordable chips. Intels new workstation processors bring many important technological advancements that greatly benefit a wide range of disciplines from Engineering to Data Science to Media & Entertainment. PCIe 5.0 provides the highest possible throughput between CPU and GPU or SSD, including support for CXL devices. Couple that with higher CPU performance across all workloads, these new Xeon workstation CPUs can also crunch memory intensive workloads faster with DDR5 memory and AI/DL workloads have more floating point formats to choose from.Form Factor
CEB
304.8W x 266.7D mmCPU
Intel Xeon W-3400 Processors
Intel Xeon W-2400 Processors
Single processor, TDP up to 350W
Carriers for Intel Xeon W-2400 Processors are not included. Please refer to the optional parts for proper support.
Notice: Please select Intel Xeon W-3400 Processors to enable all functions.Socket
1 x LGA 4677
Socket EChipset
Intel W790Memory
8 x DIMM slots
DDR5 memory supported only
8-channel memory architecture
RDIMM up to 64GB supported
3DS RDIMM up to 256GB supported
Memory speed: Up to 4800 MT/s
Only 4 x DIMM slots are supported with Intel Xeon W-2400 Processors.
Note: When installing memory modules, make sure to begin with the first socket of each channel, such as DIMM_P0_A0, DIMM_P0_B0, DIMM_P0_C0, DIMM_P0_D0.LAN
2 x 10Gb/s LAN ports (1 x Intel X710-AT2)
Support NCSI function
1 x 10/100/1000 Mbps Management LANVideo
Integrated in Aspeed AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200 at 60Hz 32bppAudio
Realtek ALC897 HD Audio Codec
Supports 2/4/5.1/7.1 channel configurations
3 x Audio Jacks (Audio in/Audio out/Mic)Storage Interface
PCH:
- 2 x SlimSAS connectors for 8 x SATA 6Gb/sRAID
Intel SATA RAID 0/1/10/5Expansion Slots
Slot_7: PCIe x16 (Gen5 x16) slot, from CPU
Slot_6: PCIe x16 (Gen5 x16) slot, from CPU
Slot_5: PCIe x16 (Gen5 x16) slot, from CPU
Slot_4: PCIe x16 (Gen5 x16) slot, from CPU
Slot_3: PCIe x16 (Gen4 x16) slot, from CPU
Slot_2: PCIe x16 (Gen5 x16) slot, from CPU
Slot_1: PCIe x16 (Gen4 x16) slot, from CPU
2 x M.2 slots:
- M-key
- PCIe Gen4 x4, from PCH
- Support 2280 cards
Slot_4/5/6 are not supported with Intel Xeon W-2400 Processors.Internal I/O
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU fan header
6 x System fan headers
1 x Front audio header
1 x USB 3.2 Gen1 x2 header
2 x M.2 slots
2 x SlimSAS connectors
1 x VROC connector
1 x Front panel header
1 x Backplane board header
1 x PMBus header
1 x IPMB header
1 x TPM headerRear I/O
1 x USB 3.2 Gen2x2 (Type-C)
3 x USB 3.2 Gen2x1 (Type-A)
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
3 x Audio jacks
1 x ID button with LEDTPM
1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010OS Compatibility
CentOS Stream 9 (x64)
Debian 11.5.0
Red Hat Enterprise Linux 9.0 (x64)
Ubuntu 22.04 LTS (x64)
Windows 11 Enterprise (x64)Board Management
ASPEED AST2600PSU Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectorsOperating Properties
Operating temperature: 10oC to 40oC
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40oC to 60oC
Non-operating humidity: 20%-95% (non-condensing)Retail Packaging Content
1 x MW83-RP0
1 x I/O shield
1 x Quick start guide
1 x W-3400 (E1A) carrier
1 x SlimSAS to 4 x SATA 6Gb/s cable (600mm)
Carriers for Intel Xeon W-2400 Processors are not included. Please refer to the optional parts for proper support.
Single Box dimensions: 360 x 330 x 80 mm
Carton dimensions: 674 x 424 x 385 mm
Quantity: 10 x single boxes in one cartonBulk Packaging Content
10 x MW83-RP0
10 x I/O shields
10 x W-3400 (E1A) carriers
Carriers for Intel Xeon W-2400 Processors are not included. Please refer to the optional parts for proper support.
Carton dimensions: 600 x 473 x 495 mm Shipping
